Solar Photovoltaic PVB Film

Solar Photovoltaic PVB Film


Duoli photovoltaic PVB film has the characteristics of high transparency, high absorption, excellent heat insulation, UV protection, moisture-proof and so on. They are still highly reliable even exposed to severe outdoor weather conditions for a long time.

Technical Parameters

Characteristics
Unit
DATA

Density
g/cm3
1.06

Refractive index
--
1.48

Tensile strength
Mp
≥20

Elongation at break
%
≥200

Hardness
ShoreA
65

Melting point
95-100

Heat conductivity
W/(m2*k)
4.15(25°C)

Coefficient of thermal
expansion
1/K
2.2x10-4

Volume resistivity
Ω*cm
1013

Light transmittance
%
≥89

Haze ratio
%
≤0.6

Peel strength
N/10mm
≥40

*H2Ocontent is 0.5%






Texture Of Material
